ZFC100-04B

Vacuum Air Source Filter ZFC series

High-precision fiber filter element, with a filtration accuracy of 10 microns, protecting vacuum components in the clean air path

No tools required. Just unscrew the end cover to remove and replace the filter element.

The resin material pipe-shaped housing is small in size yet sturdy. It is equipped with stainless steel snap rings, which are resistant to rust and corrosion, and have a long service life. The operating temperature range is 0 ℃to 60℃.

High-quality sealing rings provide multiple layers of protection, ensuring no air leakage and enabling efficient production.
